Parameters

21 reportable Parameters: WBC, Lym#, MID#, GRAN#, LYM%, MID%,GRAN%, RBC, HGB, HCT, MCV,MCHC, RDW-CV,RDW-SD, PLT,MPV,PDW, PCT,P-LCR, P-LCC

Performance

Parameter	Precision	Linear Range	Contamination Rate
WBC	< 2.0% (3.5-15.0x10⁹)/L	(0-100.0x10⁹)/L	_0.5%	< 0.5%
RBC	< 1.5% (3.0-6.0x10¹²)/L	(0.10-8.00x10¹²)/L	< 1.0% (70-120)fL	< 0.5%
HGB	< 1.5% (100-180)g/L	(0-250)g/L	-	< 0.6%
MCV	< 1.0% (70-120)fL<	-	(0.1000x10⁹)/L	-
PLT	< 4.0% (150-500x10⁹)/L	(0.1000x10⁹)/L	-	< 1.0%

Sample

Predilution Mode   20 L

Whole Blood Mode   9 L

Efficient

60 Samples per hour

Storage

Up to 50,000 results including histograms, and patiet information

Compatibility

Build-in thermal printer External laser or inkjet printer 4 USB, 1 LAN support protocol Hl7 and compatible with LIS system

Environment

Working Voltage:   Ac100V 240V, 50 60Hz
Rated Power:   40-60VA
Working Temperature:   10°C 40°C
Relative Humidity:   20%-85%

Power Requirement

100v-200v
< 300VA
50Hz/60Hz

Reagent

Diluent 20L Build-in LYSE
Probe Cleanser

Display

10.4 inch colorful touchscreen

Dimension and weight

Dimension: Depth(400 mm)x width(285 mm)
x height (400 mm)
Weight: _20 Kg
